Non Leak Micro Solenoid Valve 6V 2.5MM Orifice Direct Acting CEME 5515-10 Type

Non Leak Micro Solenoid Valve 6V 2.5MM Orifice Direct Acting CEME 5515-10 Type

1. How To Order

Model Orifice Port Thread Body Seal Coil Voltage

5566 1.0, 2.0, 3.0, 1/8" , 1/4", G- G B-Brass N-NBR SA11B 1-AC220V 2.DC24V

4.0, R- BSPT V-FRM/Viton 3-AC110V 4.DC12V

N-NPT E-EPDM 5-AC24V 6.DC6V

55​ Non Leak Micro Solenoid Valve 6V 2.5MM Orifice Direct Acting CEME 5515-10 Type

Example : 5566 GBV SA11B2: 5566 Series, normal closed, 4.0mm orifice, G1/4", Brass body, NBR seals, coil SA11B, DC24V.

2. Solenoid Valve Specification

Medium: Air, water, steam, etc. Temperature: EPDM seal:-30℃~120℃(-22℉~248℉)

Orifice: 15, 20, 25, 32, 40,50(mm) Viton seal:-30℃~150℃(-22℉~302℉)

NBR seal:-10℃~80℃(14℉~176℉)

Pressure: 5566:0.0MPA~1.0MPA (0PSI~145PSI) Port size: 1/8”, 1/4”,or customized

Tolerance: ±10% Port thread: BSPT, G Thread

Voltage: AC220V DC24V Coils: SA11B

Material: Body- PTFE Character: 1.Isolation Piston structure, longer life time,

Seal- VITION, EPDM, PTFE new PTFE seals, ambient is completely isolated

Armature- SS304 from metal parts

Plunger- SS430F 2. used in Alkali, Acid, Salts etc.

Stop- SS430F

Spring- SS304

3. Detailed Information

Non Leak Micro Solenoid Valve 6V 2.5MM Orifice Direct Acting CEME 5515-10 Type

4. Packing Detail

Plastic Sealed packing to prevent metal being oxidized.
